DCP-30 / 30 TOP 4


STANDARD DIMENSIONS
Model TCP-30 TOP-4
Length mm 1640 1360
Height mm 1000 1000
Width mm 1520 2500

    The refreshing DCP unit is a compact evaporative air cooling unit and is suitable for
     numerous fields of applications: specifically greenhouse, poultry, and dairy applications.

    *Pre coated galvanised steel housing.
    *Tank manufactured in thermoplastic material.
    *Electrical motor with IP55 protection grade.
    *Contains CELdek 7090-15 evaporative cooling pads.
    *Circulation water unit is CE approved.
    *Complete plumbing kit incorporated.
    *Electrical enclosure with safety and control switchgear.

PC-7500


STANDARD DIMENSIONS
Length mm 1555
Height mm 1342
Width mm 1555
Airflow at 0 Pa m3/h [cfm] 12675[7500]
Motor Power* kW [hp] 0.78 [0.65 fan + 0.35 pump]

    Pre-coated galvanised steel body.
    *Electrical motor with IP55 protection grade.
    *CELdek 5090-10 evaporative cooling pads.
    *Circulation water unit is CE approved.
    *Complete plumbing kit incorporated.
    *Electrical enclosure with safety and control switch gear.
    *Single-phase.

PC-5000


STANDARD DIMENSIONS
Length mm 1555 915
Height mm 1372 1738
Width mm 644 915
Airflow at 0 Pa m3/h [cfm] 8450[5000]
Motor Power* kW [hp] 0.78 [0.65 fan + 0.35 pump]

    The unique design yeilds a cooling pad with a high evaporation efficiency and economical use     of material.
    *Superb wetting properties.
    *Self cleaning design.
    *Strong and self supproting.
    *Low pressure drop when wet, leading to lower operating costs.
    *No water carry-over.
    *Long life time and low running costs.
    *Environmentally friendly.
    *Quick and easy to install.
    *Consistant high quality.

PCC-10-18X/S/C-1


STANDARD DIMENSIONS
Air Flow (m3/h) 18,000 / 10,000 CFM
Air Pressure 200
Power Consumption (KW) 1.1
Power Supply (V/Hz) 220/50
Speed Variable

    A complete water supply and drainage system for wetting of evaporative cooling pad walls.
    *Resistant to corrosion.
     *Designed to ensure an even wetting of the entire pad wall.
    *Flexible positioning of the water supply and discharge.
    *Fits any size of pad in height and width.
     *Available as complete system with all fitting parts.
    *Water filtration available upon request.
    *Quick and easy to install.

PCC-10-18X/S/C-1


STANDARD DIMENSIONS
Air Flow (m3/h) 30,000 / 18,000 CFM
Air Pressure 300
Power Consumption (KW) 3.0
Power Supply (V/Hz) 380/50
Speed Variable
Controllar Type LCD Panel
Water Tank / Consumption(L) L/h 40/10-50
Effective Area (dB) 100-150

    A complete water supply and drainage system for wetting of evaporative cooling pad walls.
    *Resistant to corrosion.
     *Designed to ensure an even wetting of the entire pad wall.
    *Flexible positioning of the water supply and discharge.
    *Fits any size of pad in height and width.
     *Available as complete system with all fitting parts.
    *Water filtration available upon request.
    *Quick and easy to install.
