EC52 Cone Fan


STANDARD DIMENSIONS
Model Propeller Diameter No of blades Motor size Airfloe at 0 Pa Specific performance at 0 Pa
EC52 1335 mm [52"] 4 0.75 or 1.5 kw 42,417 to 50,217 m3/h 44.2 to 32.47 m3/h/W

    Family member of time proven Euroemme fan range.
    *High airflow energy efficient and high static pressure.
    *Compact transportation.
    *Special cone design for optimal use of installation space.
    *Patent pending shutter opening device.
    *Four blade propeller for reduced vibrations.
    *Optional belt tensioner.

EC50 Cone fan


STANDARD DIMENSIONS
Model Propeller Diameter No of blades Motor size Airfloe at 0 Pa Specific performance at 0 Pa
EC50 1270 mm [50"] 3 0.75 or 1.1 kw 40,420 to 46,260 m3/h Up to 38.6 m3/h/W

    High efficiency extraction fan, ideally suited for livestock housing.
    *Patented centrifugal system permits a fully and firm opening of shutter.
    *High airflow capacity at high static pressure and low energy consumption.
    *Equipped with a discharge cone.

Em52 exhaust fan


STANDARD DIMENSIONS
Model Propeller Diameter No of blades Motor size Airfloe at 0 Pa Specific performance at 0 Pa
EM52 1334 mm [52"] 6 1.5 kw 43,357 m3/h 25.8 m3/h/W

    Family member of the tme proven Euroemme fan range.
    *Fan built with outstanding strength for assuring high airflow at static pressure of Upto 100Pa.
    *Fan housing an venturi made of strong galvanised sheet-steel.
    *Redesigned 52" propeller suited for high static pressure environments.
    *Shutters are made of pressed galvanised steel in order to ensure highest strength.
    *Patented centrifugal system permits an energy efficient solution.

em50 exhaust fan


STANDARD DIMENSIONS
Model Propeller Diameter No of blades Motor size Airfloe at 0 Pa Specific performance at 0 Pa
EC50 1270 mm [50"] 6 0.75 or 1.1 kw 36,180 to 42,125 m3/h Up to 34.5 m3/h/W

    The best selling agricultural extraction fan in the world.
    *Patented centrifugal system permits a fully and firm opening of the shutter.
     *Centarl hub and v-belt pully are made from die-cast aluminium.
    *Low energy consumption thanks to high aerodynamic efficiency.

em36 exhaust fan


STANDARD DIMENSIONS
Model Propeller Diameter No of blades Motor size Airfloe at 0 Pa Specific performance at 0 Pa
EC36 1270 mm [50"] 6 0.37 or 0.75 kw 17,900 to 22,250 m3/h Up to 25.1 m3/h/W

    Ideally suited for minimum ventilation of livestock houses.
    *Patented centrifugal system permits a fully and firm opening of the shutter.
     *Centarl hub and v-belt pully are made from die-cast aluminium.
    *Low energy consumption thanks to high aerodynamic efficiency.
